LR2 (LF) L6-3.2L (2008)
/l6-3.2l/Page-494001.png)
Accessory Shaft: Service and Repair
Accessory Drive Shaft Front Seal
Accessory Drive Shaft Front Seal
Special Service Tools
Removal
1. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
2. Remove the cover and disconnect the battery ground cable.
3. Remove the generator.
4. Remove the generator coupling bolt.
Special Service Tools: Holder, Generator Coupling
5. Remove the generator coupling.
Special Service Tools: Puller, Generator Coupling
6. Remove and discard the seal.
