LR3/Disco 3
Installer, crankshaft seal
303-1100
Removal
1 .
Disconnect the battery ground cable. For additional information, refer to
Specifications
(Section 414-
00)
2 .
WARNING: Do not work on or under a vehicle supported only by a jack. Always support the
vehicle on safety stands.
Raise and support the vehicle.
3 .
Remove the accessory drive belt. For additional information, refer to
Accessory Drive Belt (86.10.03)
(Section 303-05)
4 .
Remove the cooling fan shroud.
Release 2 clips from the cooling fan lower shroud.
Release and remove the cooling fan lower shroud from the cooling pack.
5 .
Using the special tools, retain the crankshaft pulley.
