LR3/Disco 3
The technical features include:
60 degree 'vee' 6 cylinder engine with a CGI cylinder block
Plastic cylinder head cover
Two light, high strength, aluminium cylinder heads
4-valve technology with centrally arranged fuel injectors
Steel roller rockers with hydraulic lash adjusters
Twin plenum intake system integrated with the camshaft cover
Variable Geometry Turbocharger
Common rail direct fuel injection system
High pressure fuel pump
Gallery cooled pistons with a central crown bowl
Two electronically controlled Exhaust Gas Recirculation (EGR) valves
Two EGR coolers
Exhaust re-treatment by means of a diesel specific oxidation catalytic converter and primary catalytic converter
Cooling fan with electro-viscous clutch drive.
ENGINE DATA
The technical data is detailed below:
CYLINDER BLOCK COMPONENTS
DESCRIPTION
TYPE
Configuration
60 degree V6
Maximum power
147 kW at 4000 rpm
Maximum torque
440 Nm at 1900 rpm
Displacement
2720cc
Stroke/bore
81mm/88mm
Compression ratio
17.3:1
Firing order
1 4 2 5 3 6
Oil capacity
6.55 litres (initial fill) 5.45 litres (service fill, includes oil filter)
Engine weight (with oil) 235kg (Automatic) 260kg (Manual, inc. clutch plate and cover)
