LR3/Disco 3
Torque Specifications
Maximum power
147 kW (200 PS) (197 bhp) @ 4000 rev/min
Maximum torque
440 Nm (324 lb-ft) @ 1900 rev/min
Engine oil
pressure:
At idle
0.7 bar (70 kPa) (10 lb/in²)
At 3500 rev/min
1.9 bar (190kPa) (27.5 lb/ft²)
Description
Nm
lb-ft
Accessory drive belt idler retaining bolt
47
35
Accessory drive belt tensioner M8 retaining bolts
47
35
Accessory drive belt tensioner M10 retaining bolts
25
18
Air conditioning (A/C) compressor retaining bolts
23
17
A/C compressor mounting bracket retaining bolts
23
17
A/C compressor low pressure pipe fixing
9
7
A/C manifold retaining bolt
20
15
Battery positive cable mounting bolts
10
7
* Camshaft inner bearing cap retaining bolts
Stage 1: tighten bolts 1 to 14
1
1
Stage 2: tighten bolts 1 to 14
5
4
Stage 3: tighten bolts 1 to 14
10
7
* Camshaft outer bearing cap retaining bolts
Stage 1: tighten bolts 1 to 4
1
1
Stage 2: tighten bolts 1 to 4
5
4
Stage 3: tighten bolts 1 to 4
10
7
Camshaft position sensor retaining bolt
10
7
+¹ Camshaft hub retaining bolts
Stage 1
80
59
Stage 2
Further 90° Further 90°
Camshaft pulley retaining bolts
23
17
Camshaft timing belt cover securing bolts
10
7
+² Crankshaft pulley retaining bolt
Stage 1
100
74
Stage 2
Further 90° Further 90°
Crankshaft damper bolts
14
10
Crankshaft position sensor retaining bolt
5
4
Crankshaft rear seal retainer plate
10
7
Coolant outlet elbow
10
7
*+² Cylinder head retaining bolts
Stage 1
20
15
Stage 2
40
30
Stage 3
80
59
Stage 4
Further 180° Further 180°
Differential front mounting bracket heat shield
10
7
EGR valve inlet tube
10
7
EGR valve mounting bolts
10
7
