LR3/Disco 3
Warning Indicator Functionality
HDC fault
Amber
Yes
E
DSC / Traction control
Amber
Yes
E
Left turn signal
Green
No
E
Right turn signal
Green
No
E
Trailer
Green
No
E
High engine coolant temperature
RED
Yes
S
High beam
Blue
No
E
ABS failure
Amber
* Yes
E
Low fuel level
Amber
Yes
S
Cruise control
Amber
No
E
Park Brake City mode
Non-functional -
-
Park brake fault
Amber
Yes
E
Park brake warning
Red
No
E
Front fog lamps
Green
No
E
Rear fog lamps
Amber
No
E
Alarm
Red
No
E
EMS Fault
Amber
Yes
E
Driveline fault
Amber / Red
Yes
E
Driveline overheat
Amber
Yes
E
Low washer fluid
Amber
Yes
E
Door open
Red
No
E
Auxiliary heater (non-functional - bulb
check only)
Red
Yes
E
Tyre pressure monitoring
Amber
Yes
E
Low coolant level
Amber
No
E
Overspeed
Amber
No
E
Water in fuel
Non-functional -
-
Tyre pressure warning
Amber
Yes
E
Brake warning
Amber / Red
Yes
E
Adaptive front lighting
Amber
Yes
E
* = Bulb check performed by
subsystem module, not instrument
cluster
