LR3/Disco 3
Installation
1 .
CAUTION: A new audio unit is supplied with a transit plate installed. This transit plate must be
removed, before installing the audio unit.
Install the audio unit.
Attach the antenna cable.
Connect the electrical connectors.
Tighten the Torx screws.
2 .
Install the climate control assembly.
Tighten the Torx screws.
3 .
Install the instrument panel console. For additional information, refer to
Instrument Panel Console
(76.25.03)
(Section 501-12 Instrument Panel and Console)
4 .
Using T4, configure a new audio unit.
