LR3/Disco 3
Anti-Theft Alarm Horn with Integral Battery
Removal
Installation
Published : Feb 4, 2005
1 .
Remove the auxiliary battery box cover.
Release the 2 clips.
2 .
Remove the anti-theft alarm horn.
Disconnect the electrical connector.
Remove the 2 bolts.
1 .
Install the anti-theft alarm horn.
Tighten the bolts to 10 Nm (7 lb.ft).
Connect the electrical connector.
2 .
Install the auxiliary battery box cover.
