LR3/Disco 3
Exterior Mirror Glass (76.11.08)
Removal
Installation
Published : Jul 28, 2004
1 .
Tilt the exterior mirror glass upwards.
2 .
Release the exterior mirror glass.
Carefully apply an even pressure to the base of the glass at two points, to release the 3
clips.
3 .
Remove the exterior mirror glass.
Release the glass from the motor.
Disconnect the 2 electrical connectors.
1 .
Install the exterior mirror glass.
