LR3/Disco 3
Exterior Mirror (76.11.10)
Removal
Installation
Published : Mar 23, 2004
1 .
Remove the front door trim panel. For additional information, refer to
Front Door Trim Panel
(76.34.01)
(Section 501-05)
2 .
Remove the exterior rear view mirror.
Disconnect the electrical connectors.
Remove the 3 bolts.
1 .
Install the exterior rear view mirror.
Tighten the bolts to 6 Nm (4 lb.ft).
Connect the electrical connectors.
2 .
Install the front door trim panel. For additional information, refer to
Front Door Trim Panel (76.34.01)
(Section 501-05)
