LR3 (LA) V6-4.0L (2006)
/v6-4.0l/Page-878001.png)
Electronic Throttle Actuator: Description and Operation
Throttle Control System
Description
The Electronic Throttle Interface consists of 2 PWM output drives to control the throttle blade position, with 2 analogue signals for throttle position
feedback. The 2 position signals have positive linear characteristics.
