LR3 (LA) V6-4.0L (2006)
/v6-4.0l/Page-1912001.png)
Suspension Strut / Shock Absorber: Service and Repair
Front Suspension
Front Air Shock Absorber
Front Air Shock Absorber
Service Repair No - 60.30.02.45
Special Service Tools
Removal
NOTE: This procedure should also be used to remove the front air spring.
1. Remove the shock absorber and spring assembly.
2. Remove the nut, rebound washer and rubber bushing.
^
Discard the nut.
3. Remove and discard the O-ring seals and spacer.
