Component Locations|Page 7576 > < Cruise Control Module|Locations|Page 7569

LR3 (LA) V8-4.4L (2009)

  • Instrument Panel, Gauges and Warning Indicators
  • Brake Warning Indicator
  • Brake Pad Wear Sensor
  • Component Information
  • Locations
  • Component Locations

Page 1
background image

Brake Pad Wear Sensor: Component Locations

Front Brakes

Component Locations

Rear Brakes

Component Locations
