TRANSFER BOX
NEW RANGE ROVER
14
DESCRIPTION AND OPERATION
Range information - Manual transmission
High range
When the transfer box is in high range, the message
centre does not display any transmission information
and the high/low request switch indicator lamp is off.
High to low range
When a change from high to low is requested:
•
The high/low switch indicator lamp flashes
•
The transfer box warning lamp in the instrument
pack flashes.
When the range change is complete:
•
The high/low switch indicator lamp is illuminated
continuously
•
The transfer box warning lamp goes off
•
A ’LOW’ message is continuously displayed in
the message centre.
Low to high range
When a change from low to high range is requested:
•
The high/low switch indicator lamp flashes
•
The transfer box warning lamp in the instrument
pack flashes.
When the range change is complete:
•
The high/low switch indicator lamp goes off
•
The transfer box warning lamp goes off
•
The message centre displays ’HIGH’ for several
seconds.
Range selection parameters incorrect
If a range change is requested and the vehicle speed
is too high:
•
The high/low switch indicator lamp will flash
•
The transfer box warning lamp in the instrument
pack will flash
•
A ’SLOW DOWN’ message is displayed in the
message centre.
If a range change is requested and the transmission is
in gear or a gear selected before range change is
complete:
•
The high/low switch indicator lamp will flash
•
The transfer box warning lamp in the instrument
pack will flash
•
A ’SELECT NEUTRAL’ message is displayed in
the message centre for several seconds. If the
vehicle remains in gear the message will not be
repeated.
Transfer box to neutral
When a spare fuse (5 Amp minimum) is inserted in
BeCM fuse position 11 to select transfer box neutral:
•
A five second delay is initiated before the
transfer box moves to neutral
•
The BeCM initiates an audible warning
•
A ’TRANSFER NEUTRAL’ message is displayed
in the message centre.
