Range Rover P38
84
WIPERS AND WASHERS
NEW RANGE ROVER
4
FAULT DIAGNOSIS
9. Symptom - Headlight Wiper Arm/Blade Inoperative.
POSSIBLE CAUSE
REMEDY
1. Loose or disconnected wiper
motor multi-plug.
1. Reconnect multi-plug.
2. Loose wiper arm fixing.
2. Secure fixing
10. Symptom - Headlight Washer Jets - Inoperative Or Functioning Erratically.
POSSIBLE CAUSE
REMEDY
1. Empty washer reservoir.
1. Refill washer reservoir.
2. Washer jet/s blocked.
2. Clear obstruction with a needle or strand of wire.
3. Loose or disconnected washer
tubes/connectors.
3. Check and secure all relevant connections.
4. Faulty non return valve.
4. Renew non return valve.
5. Screen wash flow restricted or
blocked in washer tubes.
5. Check for kinks in washer tubes or that retaining clips are not over
tightened.
6. Loose or disconnected
headlight washer pump
multi-plug.
6. Reconnect multi-plug.
7. Faulty or inoperative washer
pump.
7. Renew washer pump.
11. Symptom - ’Low Screen Wash Level’ - Shown On Message Centre.
POSSIBLE CAUSE
REMEDY
1. Screen wash level low in
reservoir.
1. Refill washer reservoir.
2. Low level sensor plug loose or
disconnected.
2. Reconnect sensor plug.
3. Faulty low level sensor.
3. Renew sensor.
