Range Rover P38
87
NAVIGATION SYSTEM
NEW RANGE ROVER
22
DESCRIPTION AND OPERATION
Map Scale
Changes the scale of the map shown on the map
guidance display. To change the map scale use the
rotary menu controller to bring up the menu, and from
the menu select scale. The scale can then be
changed between 100 metres and 100 kilometres
(125 yards and 50 miles).
Routes List
The route list menu option displays a list of all the
routes, with route titles, available to the system. The
routes are sorted alphabetically and the default cursor
position is the first route in the list. If guidance is being
given for a route, then the route text shown in the
route list is gold in colour and the default cursor
position will be the current route.
Go To
This option allows the user to be given guidance to a
selected individual destination. An audible
conformation is given once guidance has been
selected. The user inputs the destination with the text
input screen and map input screen. The text input
screen is used to input the destination title and may
be used to input the destination co-ordinates.
End Guidance
The end guidance menu option allows the user to end
the guidance information that is currently being given.
End guidance will end all types of guidance specified.
The guidance screens no longer give guidance
information and all audio instructions are halted.
Settings
The settings menu option allows the user to change
the off road navigation settings. The following settings
are available:
•
The guidance screen can be set to either full
information or reduced information.
•
The acceptance radius for notification of arrival
at waypoint can be set to between 50 metres
and 500 metres (50 yards and 550 yards). The
waypoint acceptance radius is used for all
destinations within off road navigation.
Help
The Off Road Navigation Help menu option gives the
user basic ’on line’ help. The ’on line’ help is given in
the user selected language. The user selects the
required help topic from the help index. The help list
comprises of:
•
Routes
•
Review Route
•
Delete Route
•
Copy Route
•
Paste as New
•
New Route
•
Waypoints
•
Insert Waypoint
•
Insert Current Position
•
Copy Waypoint
•
Paste Waypoint
•
Delete Waypoint
•
Edit Waypoint
•
Go To
•
Timing
•
Backtrack.
