Water ingress-front footwell

WATER INGRESS-FRONT FOOTWELL

Model

Range Rover

Affected vehicles

All derivatives from LH 647645

Date

1994-06-15

Reference

15/06/94

Bulletin text

Water Ingress-Front Footwell

MODEL AFFECTED VEHICLES

Range Rover All derivatives from LH 647645

DETAIL

It has been noted that water can enter the inside of the vehicle via the electrical harnesses that pass through the bulkhead. The water entry points are via the engine harness breakouts from the main harness where the tape wrap is incomplete around the breakout points, the water will enter these breakouts and track down the inside of the harness insulation tubing and exit at the first point on the inside of the vehicle. Water can also enter via the harness grommet located in the bulkhead.

ACTION REQUIRED

Upon customer complaint of water ingress into either left or right hand footwell inspect harness breakout points that are in the proximity of the bulkhead and bulkhead grommets around harness entry points for sealing integrity.

PARTS INFORMATION

Sikaflex 221

PROCEDURE

Check tape wraps around harness breakout points located in the engine compartment that are located in close proximity to the bulkhead. and where necessary ensure a water tight seal.

Inspect the bulkhead harness grommets for sealing integrity and reseal as necessary using Sikaflex 221.

Refer to the illustrations opposite and overleaf for affected harnesses.

15/06/94

76/19/94/EN

WARRANTY

Normal warranty policy and procedures apply.

COMP. CODE

7G0

SRO

86.70.89/27 - 00.40 hour

Water Ingress-Front Footwell

MODEL AFFECTED VEHICLES

Range Roer All derivatives from LH 647645

15/06/94 76/19/94/EN
