Rear wiper fuse

REAR WIPER FUSE

Model

Range Rover

Affected vehicles

All Range Rover derivatives from VIN LH 610295 to LH 644068

Date

1994-02-11

Reference

11/02/94

Bulletin text

Rear Wiper Fuse

MODEL AFFECTED VEHICLES

All Range Rover derivatives from VIN LH 610295 to Range Rover LH 644068

DETAIL

A rear wiper fuse rating increase was introduced onto Range Rover at VIN LH 644068 which increased the fuse rating from 10 amps to 15 amps (Maximum). This change was introduced to overcome a concern in markets where very low ambient temperatures could cause the rear wiper blade to freeze to the rear screen, if the rear wiper is operated in this condition, the current draw could overload the fuse and render the system inoperative.

Vehicles identified in the above VIN range can be fitted with the uprated fuse if this problem is a particular concern in cold climate markets.

ACTION REQUIRED

Upon customer complaint replace the existing 10 amp fuse with a 15 amp (Maximum) fuse.

PARTS INFORMATION

Not applicable

PROCEDURE

Locate fuse E3 under the front left hand seat, remove the existing fuse and replace with a 15 amp (Maximum) fuse.

WARNING: Do not use a fuse with a rating higher than 15 amps.

11/02/94

86/02/94/EN

WARRANTY

Not applicable

COMP. CODE

Not applicable

SRO

Not applicable
