Range Rover Classic
CHASSIS AND BODY
57
REPAIR
SLIDE AND GUIDE CHANNEL ASSEMBLIES OR
SUNSHADE PANEL
Service repair no - 76.82.71 / 76.82.03
NOTE: The following can be carried out
without removing complete sunroof
assembly.
The sunshade panel is removed by releasing,
either left or right slide and guide channel
assembly, instructions 1. to 12.
Remove
1. Remove glass panel assembly.
See Glass
Panel Assembly
2. Remove sunroof wind deflector assembly.
See
Wind Deflector Assembly
3. Remove rear cross member drain channel.
4. Move tilt slide rearwards until location cam is
clear of locator block.
5. Remove locator block.
6. Move tilt slide forwards until location cam has
reached position it normally locates into locator
block. Manually adjust the cam outwards to allow
tilt slide to pass and attain full tilt position.
