ENGINE
OVERHAUL
17
Timing cover - remove - Engine numbers with
suffix B
NOTE: Timing cover, oil pump, oil
pressure by-pass valve and oil pressure
relief valve are only supplied as an
assembly.
1. Secure tool LRT-12-080 to crankshaft pulley
with 2 bolts.
2. Restrain crankshaft pulley using LRT-121-080
remove crankshaft pulley bolt and collect
spacer washer; remove crankshaft pulley.
3. Remove sump.
4. Remove 2 bolts securing oil pick-up pipe to
timing cover.
5. Noting their fitted position, progressively
slacken then remove bolts securing timing
cover to cylinder block.
CAUTION: Do not attempt to remove oil
pump drive gear at this stage.
6. Release timing cover from oil pick-up pipe,
remove cover.
NOTE: Dowel located.
7. Remove and discard ’O’ ring from oil pick-up
pipe.
