Navigator 2WD V8-5.4L SOHC VIN L (1999)
Brake Rotor/Disc: Service and Repair
Disc Backing Plate
Front
Removal
1. Remove the brake disc.
2. On 4x4 vehicles, remove the wheel hub.
3. On 4x2 vehicles, remove the brake disc shield.
1. Remove the brake disc shield screws.
2. Remove the brake disc shield.
4. On 4x4 vehicles, remove the brake disc shield.
1. Remove the screws.
2. Remove the brake disc shield.
Installation
