Navigator 2WD V8-5.4L SOHC VIN L (1999)

Page 1
background image

Compressor Fitting HVAC: Specifications



Manifold Tube Bolt

18-24 Nm







Manifold Tube Fitting

25.5-34.5 Nm







Tube Bracket Nut

10-14 Nm
