Navigator 4WD V8-5.4L VIN 5 (2006)
Parking Brake Actuator: Service and Repair
Parking Brake Release Solenoid
Removal and Installation
1. Disconnect the parking brake release solenoid electrical connector.
2. Remove the parking brake release solenoid.
^
Pry the mounting bracket apart slightly to release the solenoid.
^
Disengage the solenoid from the release lever.
3. To install, reverse the removal procedure.
