Town Car V8-4.6L VIN V Flex Fuel (2006)
24. Remove the intake manifold crash bracket bolt and prevent the bolt from contacting the cylinder head with a rubber band or tie strap.
25. Remove the intake manifold crash bracket bolt.
26. Disconnect the fuel rail pressure and temperature sensor vacuum and electrical connectors.
27. Remove the wire harness retainer from the LH front fuel rail stud.
28. Remove the wire harness retainer from the rear of the intake manifold.
29. Disconnect the ground connector from the RH rear fuel rail stud bolt.
30. Remove the 8 bolts and the intake manifold.
31. Remove and discard the intake manifold gaskets.
32. Clean the sealing surfaces.
Installation
1. NOTE: Align the gasket locator tabs with the slots in the cylinder head.
Install new intake manifold gaskets.
2. Install the intake manifold and hand-tighten the 8 bolts.
3. Install the 8 ignition coil-on-plugs. For additional information, refer to Ignition System.
4. Position the intake manifold crash bracket and loosely install the bolts.
