10. Install the rear window glass aligning it to the marks made previously.

11. CAUTION:  When installing urethane-installed glass parts, the vehicle must not be driven until the urethane adhesive has cured.

Adequate cure time is specified on the drive away chart for each urethane product as the temperatures and humidity vary. Inadequate or
incorrect curing can adversely affect the retention of the rear window glass.

NOTE:  The urethane adhesive must cure for a minimum of 1 hour before testing for air or water leaks.

After the urethane cures, check the rear window glass seal for air or water leaks through the urethane adhesive bead and add urethane adhesive as
necessary.

12. Connect the rear window glass electrical connectors.
13. Install the high mounted stoplamp.
14. Install the parcel shelf.
