300SD (126.120) L5-3.0L DSL Turbo (617.951) (1982)
/l5-3.0l_dsl_turbo_(617.951)/Page-1013001.png)
Suspension Strut / Shock Absorber: Diagrams
Shock Absorber
Front
Front shock absorbers
Protective cap (11o)
Hex. nuts (11a)
Tighten: bottom hex. nut to 17 Nm, top hex. nut (counter nut) to 30 Nm.
Hold piston rod with 5 mm open-end wrench.
Plate (11b)
Rubber ring (11c)
Lug bolts 110 Nm
12-point bolts (11k) 20 Nm
Shock absorber (11)
Bottom rubber ring (11d)
Plastic protective sleeve (11f)
Bottom plate (11e)
Auxiliary rubber spring or stop buffer (11h)
11a
Hex. nut
11b
Top plate
11c
Rubber ring
11o
Protective cap
