CL 500 (140.070) V8-5.0L (119.980) (1999)
/v8-5.0l_(119.980)/Page-2653002.png)
Rear door lock cover
2
Screw out screws (arrows) and remove lock cover (1) through the installation opening.
3
Remove or unhook linkage for interior door actuation (2) and central locking linkage (3) on door lock (4).
4
Screw out screws (arrows) on door lock (4).
8 Nm.
NOTE: When installing, first tighten the front screws.
