CL 500 (140.070) V8-5.0L (119.980) (1999)

Page 4
background image

10

Screw out screws (arrows) on left-hand backrest fitting.
Tightening torque: 50 Nm.

11

Screw out screws (arrows) on right-hand backrest fitting.
Tightening torque: 50 Nm.

Driver's seat adjuster without driver's seat backrest
