CLK 320 Cabriolet (208.465) V6-3.2L (112.940) (2000)

  • Brakes and Traction Control
  • Brake Assist System <--> [Power Brake Assist]
  • Vacuum Brake Booster
  • Component Information
  • Specifications
  • Mechanical Specifications

Page 1
background image

Vacuum Brake Booster: Mechanical Specifications

Tightening

Tightening Specifications

Booster Mounting Nuts .....................................................................................................................................................................................  20 Nm

Brake Booster - Pneumatic

Brake Booster - Pneumatic

Nut of brake booster carrier on front end.......................................................................................................................................................................20 Nm

Brake Master Cylinder

Brake Master Cylinder

Nut of brake master cylinder on brake booster...............................................................................................................................................................20 Nm

Front Axle Floating Caliper

Front Axle Floating Caliper

Bleed screw on front axle floating caliper.......................................................................................................................................................................7 NM

Test Values For Pneumatic Brake Booster

Test Values For Pneumatic Brake Booster

Test Values For Pneumatic Brake Booster
