Trailer Lighting Module: Description and Operation

Make

Mercedes Benz

Model

CLK Class CLK 550 Cabriolet (209.472)

Engine

V8-5.5L (273.967)

Year

2007

Section

Relays and Modules - Lighting and Horns › Trailer Lighting Module › Description and Operation

Relays and ModulesDescription and Operation

Trailer Lighting Module: Description and Operation

GF82.10-P-2106QX Trailer Recognition Control Unit, Location/Task

- with CODE (550) Trailer hitch

Component Identification
