E 300D (210.020) L6-3.0L DSL (606.912) (1996)

  • Heating and Air Conditioning
  • Air Door, HVAC
  • Air Door Actuator / Motor, HVAC
  • Component Information
  • Locations
  • Vacuum Element For Blend Flap

Page 1
background image

Air Door Actuator / Motor: Locations
Vacuum Element For Blend Flap

The blend flap vacuum elements (42, 47) are located on the air conditioning housing.
