E 420 (210.072) V8-4.2L (119.985) (1997)
/v8-4.2l_(119.985)/Page-1658001.png)
Ignition Coil: Electrical Diagrams
Ignition Coils Diagram
1
- Circuit 1
4a
- Secondary connection (GND)
15
- Circuit 15
D1
- Diode
L1
- Primary coil
L2
- Secondary coil
R4
- Spark plug
T1/1-T1/8 - Ignition coils cylinders 1 to 8
