ML 350 4MATIC (164.186) V6-3.5L (272.967) (2006)
/v6-3.5l_(272.967)/Page-1071001.png)
Connecting Rod: Service and Repair
AR03.10-P-6111-01VA Check Connecting Rod Bolts
AR03.10-P-6111-01VA Check connecting rod bolts
Test specifications for connecting rod bolts
Connecting rod bolt length inspection
1
Measure length (L).
If the length (L) exceeds maximum permissible size, the connecting rod bolts must be replaced!
