Drive/Propeller Shaft: Procedures

AR41.10-P-0050-17GZ Tightening Procedure For Rear Propeller Shaft to Transfer Case

AR41.10-P-0050-17GZ Tightening procedure for rear propeller shaft to transfer case

Propeller shaft

Propeller shaft

Special Tools

Component Identification

Removing

1

Mark position of the rear propeller shaft relative to the transfer case flange.
Apply color coding of propeller shaft position relative to the flange on the transfer case/ adapter housing in order to reproduce the plant
