SL 500 (129.067) V8-5.0L (119.972) (1994)
/v8-5.0l_(119.972)/Page-2376001.png)
Convertible Top Canvas: Procedures
Replacing Front Top Covering
Replacing Front Top Covering
Preceding:
Hardtop removed.
NOTE:
Install top covering with MB special glue, part number 000 989 92 71.
Soft top ........................................................................................................................................................................................................ unlock at front
Recessed handle (1), trim (2) .................................................................................................................................................................................. remove
Headliner (3) (previous version with retaining rail on corner brace) ...................................................................................................................... remove
Headliner (3) (modified version without retaining rail on corner brace) allow to hang ...................................................................................... downward
Covering strip (arrow) on corner brace (previous version) ....................................................................................................................................... detach
Screws (4) on corner brace .................................................................................................................................................................................. screw out
