SLK 230 (170.449) L4-2.3L SC (111.983) (2001)

Page 1
background image

Camshaft: Application and ID
AH05.20-P-0100-01AG Camshaft Code Number and Assignment

Camshaft Code Number and Assignment

The camshaft code number is located at the 2nd camshaft bearing (arrow).
