Mariner 2WD L4-2.5L (2009)
5. Install the seat backrest cover. For additional information, refer to Seat Backrest Cover - Front See: Seat Cover/Service and Repair/Front
Seats/Seat Backrest Cover - Front.
6. Install the seat backrest. For additional information, refer to Seat Backrest - Front See: Removal and Replacement/Front Seats/Seat Backrest -
Front.
Seat Backrest - Rear
Seat Backrest - Rear
NOTE: LH (60 percent) shown, RH (40 percent) similar.
