Mariner 2WD V6-3.0L VIN 1 (2006)
3. Install the special tools.
1
Position the 2 universal adapter brackets on top of the cylinder block.
2
Install 2 M8 x 1.25 x 36 mm (1.41 inch) bolts and tighten to 10 Nm (89 inch lbs.).
3
Position the universal lifting bracket onto the 2 universal adapter brackets.
4
Fasten the universal lifting bracket to the 2 universal adapter brackets with a suitable nut and bolt.
4. Using the special tools, lift the engine 12 mm (0.47 inch).
5. Remove the nut and position the PSP tube bracket aside.
^
To install, tighten to 25 Nm (18 ft. lbs.).
6. Remove the 3 nuts and the engine support insulator bracket.
^
To install, tighten to 55 Nm (41 ft. lbs.).
7. Remove the 3 bolts and the engine support insulator.
^
To install, tighten to 55 Nm (41 ft. lbs.).
