Mariner 2WD V6-3.0L VIN 1 (2006)
Refrigerant: Testing and Inspection
Fluorescent Dye Leak Detection
FLUORESCENT DYE LEAK DETECTION
Special Tool(s)
Special Tool(s)
Fluorescent Dye Detection
NOTE: Vehicles are manufactured with R-134a fluorescent dye installed in the refrigerant system from the factory. The location of leaks can be
pinpointed by the bright yellow-green glow of the fluorescent dye under a UV lamp. Since more than one leak can exist, make sure to inspect each
component, line, and fitting in the refrigerant system for a leak.
