Mariner 2WD V6-3.0L VIN 1 (2006)
3. Using the special tool, support the engine.
4. Remove the 4 LH transaxle support insulator bolts.
^
To install, tighten to 48 Nm (35 ft. lbs.).
5. Remove the through-bolt and the LH transaxle support insulator.
^
To install, tighten to 103 Nm (76 ft. lbs.).
6. Remove the 3 nuts and the LH transaxle support insulator bracket.
^
To install, tighten to 40 Nm (30 ft. lbs.).
7. To install, reverse the removal procedure.
