Mountaineer 2WD V6-4.0L VIN K Flex Fuel (2002)
Rear Door Latch: Service and Repair
REAR DOOR LATCH
Removal and Installation
1. Remove the rear door trim panel.
2. Position the watershield aside.
3. Remove the speaker.
1. Remove the screws.
2. Disconnect the electrical connector.
3. Remove the speaker.
4. Disconnect the interior door lock actuating rod.
1. Release the clip.
2. Release the rod.
5. Position the door handle aside.
1. Remove the screw.
2. Position the handle aside.
6. Disconnect the door latch jumper harness electrical connector.
