Mountaineer AWD V8-4.6L VIN 8 (2006)
8. Attach the seat back lower outer trim cover J-clip.
9. NOTE: RH shown, LH similar.
Fold the backrest trim cover over on each side of the inboard and outboard recliner. Install the plastic rivets attaching the backrest trim cover to the
inboard and outboard recliners on the seat backrest frame.
10. Install the seat backrest.
11. Install the passenger seat and repower the supplemental restraints system (SRS). Do not prove out the SRS at this time.
Passenger seat
12. Carry out the Zero Seat Weight Test and prove out the SRS. See: Testing and Inspection/Component Tests and General Diagnostics/Zero Seat
Weight Test
