Sable V6-3.0L DOHC VIN S (2002)

Page 1
background image

P0705 - P0709: Testing and Inspection
P0705

For diagnosis of code P0705 on an AX4S transmission refer to this chart:

For diagnosis of code P0705 on an 4F50N transmission refer to this chart:
