Sable V6-3.0L DOHC VIN S (2002)

Page 1
background image

P0715 - P0719: Testing and Inspection
P0715

For diagnosis of code P0715 on an AX4S transmission refer to this chart:

For diagnosis of code P0715 on an 4F50N transmission refer to this chart:
