Sable V6-3.0L DOHC VIN S (2002)
Parking Brake Cable: Service and Repair
Parking Brake Cable - Rear, LH
Parking Brake Cable - Rear, LH
Removal and Installation
All vehicles
1. Remove the left rear wheel and tire assembly.
2. NOTE: While holding the rod, turn the adjustment nut.
Slacken the parking brake cable.
3. Disconnect the LH rear parking brake cable and conduit.
4. Squeeze the retainer and pull the cable and conduit out of the body bracket.
Vehicles with drum brakes
5. Remove the brake drum.
