Sable AWD V6-3.5L (2008)
Fan Shroud: Service and Repair
Cooling Fan Motor and Shroud
Cooling Fan Motor And Shroud
Removal and Installation
1. With the vehicle in NEUTRAL, position it on a hoist.
2. Remove the air cleaner assembly.
3. Disconnect the cooling fan motor and shroud electrical connector and detach the wiring harness from the shroud.
4. Detach the upper radiator hose from the cooling fan motor and shroud.
5. Release the tab through the access hole and remove the upper radiator hose support.
