Sable AWD V6-3.5L (2008)

Page 1
background image

Seals and Gaskets: Service and Repair
Stub Shaft Seal

Stub Shaft Seal

Removal

NOTE: The rear drive unit (RDU) does not have stub shaft pilot bearings. It has stub shaft seals only.

1. Remove the halfshaft assembly.
2. Using the special tools, remove the stub shaft seal.
