Cooper Clubman (R55) L4-1.6L (N16) (2011)
/l4-1.6l_(n16)/Page-245001.png)
Front Bumper Cover / Fascia: Service and Repair
51 11 152 Removing and Installing/Replacing Center Spoiler on Bumper Trim
51 11 152 Removing And Installing/Replacing Centre Spoiler On Bumper Trim
Necessary preliminary work:
-
Remove front bumper trim.
Release left and right expanding rivets (1).
Installation note:
Replace expanding rivets.
Release latch mechanisms (1) and remove spoiler (2).
Installation note:
Latch mechanisms (1) must not be damaged.
