Cooper Convertible (R57) L4-1.6L (N12) (2009)
Convertible Top Hydraulic Control Unit: Service and Repair
54 34 005 - Removing and installing/replacing hydraulic unit for convertible top drive
Necessary preliminary tasks:
-
Open loading aid
-
Remove left wheel arch trim
Caution!
Hydraulic fluid may emerge from the disconnected lines and the open connections on the hydraulic unit.
Protect components and work area with suitable materials (e.g. cloths).
Make sure that dirt cannot get into the hydraulic circuit.
Follow repair instructions See: Service and Repair/Procedures/Repair Instructions for Convertible Top Hydraulic System for hydraulic system.
Do not fit hydraulic lines in kinked, crushed or transposed condition.
Unfasten screws.
Tightening torque 54 34 1AZ See: Specifications/54 34 Motor-Driven Convertible Top (Hydraulic Components).
