Air Door Actuator / Motor: All Technical Service Bulletins
A/C - Noise From Air Door Recirculation Motors
SI M 64 04 08
Heating and Air Conditioning
September2008
Technical Service
SUBJECT:
Noise from Recirculation Motors
MODEL:
R50 (Cooper)
R52 (Cooper, Cooper S Convertible)
R53 (Cooper S)
SITUATION
The customer may report that an unpleasant noise can be heard when the recirculation flap is actuated.
CAUSE
Recirculation motor
PROCEDURE
In the case of a customer complaint, activate and deactivate the recirculation motor by pressing the recirculation switch. If the recirculation motor is
causing an abnormal noise, replace the recirculation motor as described in Repair Instruction RA 64 11 805 "Removing and installing/replacing servo
drive for fresh-air/recirculated-air flap".
PARTS INFORMATION
WARRANTY INFORMATION
