Navigation Display: Service and Repair
Removing and Installing Complete Navigation Instrument Cluster
62 10 130 - Removing and installing complete navigation instrument cluster
Important!
Read and comply with notes on protection against electrostatic damage (ESD protection) See: Service Precautions/Vehicle Damage Warnings/Notes
on ESD Protection (Electro Static Discharge).
Necessary preliminary tasks:
-
Clamp off battery negative lead See: Starting and Charging/Battery/Service and Repair/Removal and Replacement/Disconnecting and Connecting
Battery Negative Lead
-
Remove cover for instruments
Release screws (1).
